Carlo Gavazzi G50102206 – Dupline-Powered Dual-Channel Digital Input Module
The Carlo Gavazzi G50102206 is a high-performance dual-channel digital input module designed for the Dupline® fieldbus system – Carlo Gavazzi's proprietary two-wire fieldbus technology engineered for long-distance, high-interference, and cost-effective industrial sensing and control applications. This module serves as a reliable input node that acquires field switch signals and converts them into Dupline bus signals for stable, long-distance transmission.
Key Features
Dual-Channel Digital Input – The module features two independent digital input channels, supporting dry contact, PNP, and NPN signal inputs. It quickly responds to input state changes, ensuring accurate and stable data acquisition.
Dupline Bus-Powered – The G50102206 is powered directly by the Dupline two-wire bus, eliminating the need for an external power supply. This significantly reduces wiring complexity and installation costs.
Ultra-Long Distance Transmission – Leveraging Dupline's low-frequency carrier technology, the module supports communication distances of up to 10 kilometers per bus segment, far exceeding traditional fieldbus systems like RS-485 (1.2 km).
Mini-E Housing with Flexible Mounting – The compact Mini-E housing supports both direct wall mounting and 35mm DIN rail mounting (via DIN-rail adapter), enabling rapid deployment in various industrial environments.
Built-in Pulse Prolongation – An integrated pulse prolongation function prevents signal loss caused by mechanical contact bouncing or short pulses, improving PLC acquisition success rates.
Superior Noise Immunity – The Dupline system employs low-frequency (<9.6 kHz) current-driven communication, offering exceptional resistance to electromagnetic interference (EMI) from variable frequency drives, motors, and high-voltage cables.
IP20 Protection Rating – Rated IP20, the module is suitable for installation in control cabinets and industrial control environments.
Wide Operating Temperature Range – The module operates reliably in temperatures ranging from -20°C to +50°C, making it suitable for demanding industrial conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | G50102206 |
| Product Type | Dupline Fieldbus I/O Module / Transmitter |
| Input Channels | 2 digital inputs |
| Input Type | Dry contact, PNP, NPN |
| Power Supply | Dupline bus-powered (no external power required) |
| Communication | Dupline two-wire fieldbus |
| Transmission Distance | Up to 10 km |
| Mounting | 35mm DIN rail (DRA adapter) or direct wall mount |
| Housing | Mini-E housing |
| Protection Rating | IP20 |
| Operating Temperature | -20°C to +50°C |
| RoHS Compliance | Yes |
| SVHC | No SVHC |
| Product Series | Dupline Series |
Applications
The G50102206 dual-channel input module is ideally suited for a wide range of industrial and building automation applications:
- Industrial Automation Systems – Distributed I/O control on production lines, packaging machinery, and conveyor systems
- Water Treatment & Environmental Engineering – Remote status monitoring of pumps, valves, and level sensors
- Building Automation – Lighting cluster control, security systems, and HVAC monitoring
- Power & Energy Monitoring – Solar/wind farm remote equipment monitoring, substation temperature and humidity detection
- Transportation Systems – Tunnel ventilation equipment, railway signal status feedback
- Remote Distributed Control – Ideal for scenarios with long wiring distances and dispersed field points
System Integration
The G50102206 integrates seamlessly into the Dupline fieldbus ecosystem. When combined with a Dupline gateway module (such as the SD2DUG24) and a bus configurator (such as the GAP1605), users can build a complete, efficient, and reliable fieldbus system. The system supports bus, star, and tree topologies without the need for complex termination resistors, and a single master can connect up to 250 slave devices.
Why Choose the G50102206?
- Reduce Wiring Costs – Two-wire power and communication significantly lower cabling complexity and material costs
- Enhance System Reliability – Exceptional noise immunity ensures stable signal transmission even in harsh industrial environments
- Simplify Installation – Compact design with flexible mounting options enables quick and easy deployment
- Scale with Ease – Supports up to 250 nodes per master, providing ample expansion capability for growing systems
- Proven Technology – Backed by Carlo Gavazzi's decades of expertise in industrial automation and fieldbus technology
The Carlo Gavazzi G50102206 Dupline dual-channel input module delivers a robust, cost-effective, and reliable solution for digital signal acquisition in distributed control systems, making it the smart choice for engineers seeking to optimize their fieldbus infrastructure.
